• Chrome front bumper
• Painted rear step bumper
• Molded grille painted argent
• Single rectangular halogen headlamps
• Daytime running lamps
• (5) Roof marker lamps
• Cargo area lamp
• Tailgate lamps
• Dual black break-a-way mirrors
• Solar-Ray tinted glass (all windows)
• Swing-out rear quarter windows
• Intermittent windshield wiper system
• Removable tailgate w/badge name/decal
• Insulation under dash & floor covering

• 3-passenger reclining split bench seat w/easy-entry
• 3-passenger folding rear bench seat w/matching trim
• Color-keyed rubber floor covering
• Simulated leather steering wheel
• Passlock theft deterrent security system
• Key-in-ignition warning buzzer
• Heater/defogger w/side window defoggers
• ETR AM/FM stereo-inc: seek-scan, digital clock, 4 speakers
• Glove box w/latched door
• Dual dash cup holders
• Dual covered power points
• Cigarette lighter
• Molded plastic door trim panels w/dual integral armrests/map pockets
• Color-keyed cloth headliner
• Dual color-keyed padded cloth sunshades w/driver storage strap, passenger mirror
• Passenger assist handles
• Lighting-inc: dome,reading,ashtray,glove-box,delayed entry feature,underhood
• Dual coat hooks

• Four-wheel anti-lock brake system
• Manual lap/shoulder safety belts, front/rear outboard seat positions
• Front outboard shoulder belt height adjusters
• Manual lap safety belts, center seat positions
• Head restraints, front seat
• Daytime running lamps
• Side door guard beams
• Single note horn

APPEARANCE PKG

• chrome grille
• dual composite halogen headlamps
• dual horns

PREFERRED EQUIPMENT GROUP 1

• base decor

FLEETSIDE BODY

• (STD)

HD 4-SPEED ELECTRONICALLY-CONTROLLED AUTOMATIC TRANSMISSION W/OD

• HD aux trans oil cooler
• brake/trans shift interlock

DUAL STAINLESS STEEL OUTSIDE REARVIEW MIRRORS

• 7" x 16" Velvac West Coast type. **shipped loose for dealer installation**

FRONT 60/40 RECLINING SPLIT BENCH SEAT

• easy-entry feature (STD) (w/LS Decor & __D or __2 Seat Trim center fold-down storage armrest w/coin holder/map net/writing board
• pwr lumbars
• storage pockets behind seat

SOLAR-RAY DEEP TINTED GLASS

• *rear window is light tinted w/C49 Defogger*

10,000# GVWR

• (3600 front/7500 rear)
• springs (3600 front/7500 rear)
• axles (4100 front/ 7500 rear) (STD)

5.7L (350) SFI V8 (VORTEC) ENGINE

• (STD)

LT225/75R16D ALL-SEASON SBR BSW FRONT TIRES

• (STD)

SOLID PAINT

• (STD)

• 10,000 lbs GVWR
• 4.10 Axle Ratio
• Air Conditioning Not Desired
• Deep Tinted Solar-Ray Glass
• Federal Emission Requirements
• Front License Plate Bracket
• Front LT225/75R16D AS BSW Tires
• Gray
• Indigo Blue Met
• Locking Differential
• Rear LT225/75R16D AT BSW Tires
• Reclining 60/40 Split Bench Seat
• Spare LT225/75R16D AT BSW Tire
• Stainless Steel West Coast Type Mirrors
• Vortec 5700 V8 SFI Engine
• Deluxe Front Appearance Package
• Electronic 4 Speed Heavy Duty Automatic Transmission with Overdrive
• Preferred Equipment Group 1SA
• 12V power outlets 3 12V power outlets
• 4 Speakers
• ABS brakes
• ABS Brakes 4-wheel antilock (ABS) brakes
• ABS Brakes Three channel ABS brakes
• Air conditioning No
• Alternator Type Alternator
• AM/FM radio
• Antenna Fixed audio antenna
• Ashtray
• Basic warranty 36 month/36,000 miles
• Battery charge warning
• Battery type Heavy-duty lead acid battery
• Beverage holders Front beverage holders
• Body panels Fully galvanized steel body panels with side impact beams
• Box style Standard style pickup box
• Brake type Front disc and rear drum brakes
• Bumpers front Chrome front bumper
• Bumpers rear Black rear bumper
• Bumpers: chrome
• Cab mounted cargo light
• Cabback insulator
• Cigarette lighter Front cigarette lighter
• Clearance lights Cab clearance lights
• Clock Digital clock
• Corrosion perforation warranty 72 month/100,000 miles
• Cylinder head material Iron cylinder head
• Day/Night rearview mirror
• Door ajar warning
• Door bins front Driver and passenger door bins
• Door handle material Black door handles
• Door locks Manual door locks
• Door mirror style Stainless steel door mirrors
• Door mirror type Trailer style side mirrors
• Drive type Rear-wheel drive
• Driver door bin
• Driver seat direction Driver seat with 4-way directional controls
• Driver side rear seat easy entry Manual driver side rear seat easy entry
• Dual rear wheels
• Emissions Federal emissions
• Engine block material Iron engine block
• Engine compartment light
• Engine Configuration Vortec V8
• Engine cooler Engine oil cooler
• Engine Location Front mounted engine
• Engine Mounting direction Longitudinal mounted engine
• Engine Short Vortec 5.7L V-8
• Engine Vortec 5.7L V-8 regular unleaded, engine with 255HP
• Engine/electric motor temperature gauge
• First-row windows Manual first-row windows
• Fleetside Body Code
• Floor coverage Full floor coverage
• Floor covering Full vinyl floor covering
• Folding rear seats Full folding rear seats
• Front anti-roll bar
• Front anti-roll Front anti-roll bar
• Front beverage holders
• Front head restraint control Manual front seat head restraint control
• Front head restraints Height adjustable front seat head restraints
• Front reading lights
• Front seat type Split-bench front seat
• Front seat upholstery Vinyl front seat upholstery
• Front seatback upholstery Vinyl front seatback upholstery
• Front wheel independent suspension
• Fuel Type Regular unleaded
• Gearshifter material Urethane gear shifter material
• Glove box Illuminated glove box
• Grille style Chrome grille
• Headlight type Reflector headlights
• Headlights Halogen headlights
• Headlights on reminder
• Headliner coverage Full headliner coverage
• Headliner material Cloth headliner material
• Height adjustable seatbelts Front height adjustable seatbelts
• High mount stop light High mounted center stop light
• Ignition Spark ignition system
• Ignition type Mechanical
• Illuminated glove box
• Immobilizer
• Instrumentation display Analog instrumentation display
• Interior courtesy lights Delay interior courtesy lights
• Key in vehicle warning
• License plate front bracket Front license plate bracket
• Limited slip differential Mechanical limited slip differential
• Lock-up transmission
• Manual driver seat controls Driver seat manual reclining and fore/aft control
• Manual passenger seat controls Passenger seat manual reclining and fore/aft control
• Multiple headlights Multiple enclosed headlights
• Number of doors 2 doors
• Oil pressure gauge
• Overdrive transmission
• Paint Metallic paint
• Passenger door bin
• Passenger seat direction Front passenger seat with 4-way directional controls
• Passenger side rear seat easy entry Manual passenger side rear seat easy entry
• Passenger vanity mirror
• Power steering
• Powertrain type ICE
• Powertrain warranty 36 month/36,000 miles
• Radiator
• Radio AM/FM
• Rear bumper step
• Rear cargo door Tailgate
• Rear head restraint control 2 rear seat head restraints
• Rear head restraint control Manual rear seat head restraint control
• Rear head restraints Height adjustable rear seat head restraints
• Rear seat direction Front facing rear seat
• Rear seat folding position Fold-up rear seat cushion
• Rear seat upholstery Vinyl rear seat upholstery
• Rear seatback upholstery Vinyl rear seatback upholstery
• Rear seats fixed or removable Fixed rear seats
• Rear seats Rear bench seat
• Rear Springs Regular grade rear springs
• Rear step bumper
• Rear under seat ducts Rear under seat climate control ducts
• Rear window trim Black rear window trim
• Rear windshield Fixed rear windshield
• Roadside warranty 36 month/36,000 miles
• Running lights Daytime running lights
• Seating capacity 6
• Second-row windows Manually vented second-row windows
• Seek scan
• Shock absorbers Gas-pressurized shock absorbers
• Spare tire Full-size spare tire with steel wheel
• Spare tire location Crank-down spare tire
• Speakers number 4 speakers
• Speakers Standard grade speakers
• Special paint Monotone paint
• Speed sensitive steering Speed sensitive power steering
• Speed-sensing steering
• Split front seats 60-40 split-bench front seat
• Sport steering wheel
• Springs front Front coil springs
• Springs rear Rear leaf springs
• Steering Hydraulic power-assist steering system
• Steering type Re-circulating ball steering
• Steering wheel material Urethane steering wheel
• Sun visor strip
• Suspension ride type front Independent front suspension
• Suspension ride type rear Rigid axle rear suspension
• Suspension Standard ride suspension
• Suspension type front Short and long arm front suspension
• Suspension type rear Leaf spring rear suspension
• Tachometer
• Tailpipe Stainless steel single exhaust
• Tinted windows Deep tinted windows
• Tires LT225/75SR16 AS BSW front and rear tires
• Towing wiring harness Trailer wiring harness
• Transmission 4-speed automatic
• Transmission electronic control
• Transmission oil cooler Heavy-duty transmission oil cooler
• Transmission Type Automatic
• Trip odometer
• Variable panel light Variable instrument panel light
• Variably intermittent wipers
• Ventilated brakes Front ventilated disc brakes
• Visor passenger mirror Passenger visor mirror
• Voltmeter
• Wheel covers Wheel hub covers
• Wheels 16 x 6-inch front and dual rear painted steel wheels
• Window Trim Black side window trim
• Windshield trim Black windshield trim
• Wipers Variable intermittent front windshield wipers

• Electrical
• Cold Cranking Amps @ 0° F (Primary): 600
• Maximum Alternator Capacity (amps): 100
• Maximum Alternator Watts: 1200
• Cooling System
• Total Cooling System Capacity (qts): 17.1
• Weight Information
• Gross Axle Wt Rating - Front (lbs): 3600
• Gross Axle Wt Rating - Rear (lbs): 7500
• Curb Weight - Front (lbs): 2942
• Curb Weight - Rear (lbs): 2517
• Gross Vehicle Weight Rating Cap (lbs): 10,000
• Gross Combined Wt Rating (lbs): 13,500
• Trailering
• Dead Weight Hitch - Max Trailer Wt. (lbs): 5000
• Dead Weight Hitch - Max Tongue Wt. (lbs): 500
• Wt Distributing Hitch - Max Trailer Wt. (lbs): 10,000
• Wt Distributing Hitch - Max Tongue Wt. (lbs): 1000
• Suspension
• Suspension Type - Front: Coil Spring
• Suspension Type - Rear: 2-Stage Multi-Leaf
• Spring Capacity - Front (lbs): 3600
• Spring Capacity - Rear (lbs): 7500
• Axle Type - Rear: Full-Floating
• Axle Capacity - Front (lbs): 4100
• Axle Capacity - Rear (lbs): 7500
• Axle Ratio (:1) - Rear: 4.10
• Shock Absorber Diameter - Front (mm): 35
• Shock Absorber Diameter - Rear (mm): 35
• Stabilizer Bar Diameter - Front (in): 1.25
• Brakes
• Brake Type: Power
• Brake ABS System: Four Wheel
• Disc - Front (Yes or ): Yes
• Front Brake Rotor Diam x Thickness (in): 12.50 x 1.50
• Drum - Rear (Yes or ): Yes
• Rear Drum Diam x Width (in): 13.0 x 3.5
• Tires
• Front Tire Order Code: XHP
• Rear Tire Order Code: YHR
• Rear Tire Order Code: YHP
• Spare Tire Order Code: ZHR
• Spare Tire Order Code: ZHP
• Front Tire Size: LT225/75R16D
• Rear Tire Size: LT225/75R16D
• Spare Tire Size: LT225/75R16D
• Spare Tire Size: LT245/75R16E
• Front Tire Capacity (lbs): 1940
• Rear Tire Capacity (lbs): 1875
• Spare Tire Capacity (lbs): 1940
• Revolutions/Mile @ 45 mph - Front: 706
• Revolutions/Mile @ 45 mph - Rear: 706
• Revolutions/Mile @ 45 mph - Spare: 706
• Wheels
• Front Wheel Size (in): 16 x 6.0
• Rear Wheel Size (in): 16 x 6.0
• Spare Wheel Size (in): 16 x 6.0
• Front Wheel Material: Steel
• Rear Wheel Material: Steel
• Spare Wheel Material: Steel
• Steering
• Steering Type: Power
• Steering Ratio (:1), On Center: 16.4
• Steering Ratio (:1), At Lock: 15.3
• Turning Diameter - Curb to Curb (ft): 50.2
• Turning Diameter - Wall to Wall (ft): 54.6
• Frame
• Frame Type: Ladder
• Fuel Tank
• Fuel Tank Capacity, Approx (gal): 34
• Fuel Tank Location: Inboard LH Frame
• Exterior Dimensions
• Wheelbase (in): 155.5
• Length, Overall w/o rear bumper (in): 237.4
• Width, Max w/o mirrors (in): 94.3
• Height, Overall (in): 72.6
• Overhang, Front (in): 35.4
• Overhang, Rear w/o bumper (in): 45.7
• Front Bumper to Back of Cab (in): 135.0
• Cab to Axle (in): 55.9
• Ground to Top of Load Floor (in): 34.1
• Frame Width, Rear (in): 36.7
• Ground Clearance, Front (in): 8.0
• Ground Clearance, Rear (in): 6.4
• Cargo Area Dimensions
• Cargo Box Length @ Floor (in): 97.6
• Cargo Box Width @ Top, Rear (in): 60.2
• Cargo Box Width @ Floor (in): 64.4
• Cargo Box Width @ Wheelhousings (in): 49.1
• Cargo Box (Area) Height (in): 19.2
• Tailgate Width (in): 62.0
• Cargo Volume (ft³): 69.1
• Ext'd Cab Cargo Volume (ft³): 40.5
• Interior Dimensions
• Passenger Capacity: 6
• Front Head Room (in): 40.0
• Front Leg Room (in): 41.5
• Front Shoulder Room (in): 65.0
• Front Hip Room (in): 60.1
• Second Head Room (in): 38.0
• Second Leg Room (in): 28.7
• Second Shoulder Room (in): 67.6
• Second Hip Room (in): 66.1
• Summary
• Vehicle Name: Chevrolet C/K 3500
• Body Style: Ext Cab 8' Fleetside
• Body Code: E63
